Blackburn C5-BB 1-3/4 Inch Polypropylene Compression Tap Cover
- Manufacturers: ABB
- Brand Name: Thomas & Betts (T&B)
- BPN: BLAC5BB
- MPN: C5-BB
- UPC:783786331017
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at this location:
--
-
Login for Price
- Submit Slang Term
Insulating Polypropylene Cover for All O Die taps, 1 3/4 inch long or less
| Application | : | For Secure Double-Locking Latches, Provide a Close-Fitting Top and Bottom Seal |
| Brand Name | : | Thomas & Betts (T&B) |
| Color/Finish | : | Black |
| Color | : | Black |
| Dimensions | : | 3.75 in L x 1.25 in W x 1.6 in H |
| For Use With | : | H-Type Compression Connector |
| Height | : | 1.6 Inch |
| Item Name | : | Cover |
| Length | : | 3 Inch |
| Material | : | Polypropylene |
| Mounting | : | None |
| Sub Brand | : | Blackburn |
| Trade Slang | : | 783786331017, THBC5BB, Thomas & Betts, C5-BB, H-Tap Connectors, Press-On Lugs, Lugs & Split Bolts, Connectors, Crimps, Termination |
| Type | : | Type C, Insulated |
Features
- Made from Black Polypropylene to resist UV.
- Thin strips of the "grass skirt" mold around the conductor to provide a reliable enclosure
- Tapered drains in both cover halves prevent accumulation of water.
General
- Style: H-Tap Cover
- Material: Polypropylene
- Capacity: All O Die taps, 1 3/4" long or less
Dimension Information
- Width (inches): 1.25
- Length (inches): 3.75
- Height (inches): 1.60
Packaging
- T&B Sold in UOM: Each
- T&B Weight Per UOM: 6.25 lbs. per 100
- Package Length: 10.25
- Package Width: 10.25
- Package Height: 9
- Outer Package: 100
Certifications
- RoHS Compliance: Yes
