Ilsco PBTD-4-500 Nimbus Insulated Aluminum Multi-Tap Connector, Conductor Range 600-4, 4 Ports, Dual Sided Entry, Tin Plated, UL, CSA

  • Manufacturers: ILSCO
  • Brand Name: Ilsco
  • BPN: ILSPBTD4500
  • MPN: PBTD-4-500
  • UPC:783669078442
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

Nimbus Insulated Multi-Tap Connector, Dual Sided Entry, Mechanical connection, Dual Rated, Aluminum material, Tin plated connector, UL 486A/B Listed, C22.2 No. 65-03, Copper/Aluminum Primary Conductor 600 kcmil - 4 Str, Contains DE-OX®, 4 conductors, 4 ports/wireways, Plastisol insulation, Drive Type Main 3/8 Internal Hex, rated for 600 V, primary color Black, 1 poles,

Amperage Rating      :      475 Amp
Amperage      :      475 Amp
Application      :      Insulated Multi-Tap Connector, Dual Sided Entry
Brand Name      :      Ilsco
Carton Qty      :      3
Color      :      Black
Conductor Material      :      Aluminum,Copper
Conductor Range      :      AL Solid (Primary, run, main, line):NA;CU Solid (Primary, run, main, line):NA;CU Stranded (Primary, run, main, line):600 kcmil - 4 Str;AL Stranded (Primary, run, main, line):600 kcmil - 4 Str
Conductor Type      :      Stranded
Connection Type      :      Mechanical
Connection      :      Mechanical
Environmental Conditions      :      Cold temperature rated to -45°C
Finish      :      Tin Plated
Height      :      3.034 Inch
Insulation      :      Plastisol
Length      :      5.343 Inch
Material      :      Aluminum
Number of Conductors      :      4
Number of Ports      :      4
Standards      :      CSA File Number:LR-29601;UL Control Number:453G;UL File Number:E6207;UL / CULUS Specification:UL 486A/B Listed
Sub Brand      :      Nimbus
Temperature Rating      :      90 degrees C
Trade Slang      :      783669078442, PBTM, PBTD, Nimbus, Mountable Mulit Tap Connector, Multi Tap Connector, Connector Block, ILSPBTD4500, Ilsco, PBTD-4-500, Connector Blocks - Insulated - Two Sided Wire Entry, Connector Blocks - Insulated, Distribution & Terminal Blocks, Connectors, Crimps, Termination, jonhson bar
Type      :      PBTD:INS BLK TWO SIDE TAP
Voltage Rating      :      600 Volt
Voltage      :      600 Volt

Specifications

  • Height: 3.034 in | 77.0636 mm
  • Length: 5.343 in
  • Weight: 1.533 lbs
  • Width: 3.031 in | 76.9874 mm

Additional Class Attributes

  • Connection: Mechanical
  • Contains DE-OX®: Yes
  • Number of Conductors: 4
  • Number of Poles: 1
  • Number of Ports / Wireways: 4
  • Number of Usable Ports: 4
  • Number of Usable Taps: 4
  • Replacement Part(s): PORTPLUG-500, SCREWCAP-500

Dimensions

  • Drive Size Main: 3/8
  • Drive Type Main: Internal Hex
  • Height BX (IN): 3.75
  • Height (mm): 77.0636
  • Max Insulation OD (IN): 1.115
  • Max Insulation OD (mm): 28.321
  • Weight BX (LB): 4.9128
  • Width BX (IN): 6.375
  • Width (mm): 76.9874

Additional Technical Specifications

  • Conductor Type: Stranded

Material and Finish

  • Conductor Material: Copper, Aluminum
  • Connector Finish: Tin
  • Insulation: Plastisol
  • Material: Aluminum
  • Wire Binding Hardware Finish: Tin
  • Wire Binding Hardware Material: Aluminum

Bolt and Screw Sizes

  • Number of Wire Binding Screws per Port: 1
  • Wire Binding Screw Size: 13/16
  • Wire Binding Torque: 375

Conductor Ranges

  • Conductor Range AL Stranded (Primary, run, main, line): 600 kcmil - 4 Str
  • Conductor Range CU Stranded (Primary, run, main, line): 600 kcmil - 4 Str

Voltage

  • Voltage Rating: 600 V

Color

  • Cap Color Main: Black
  • Cap Color Tap: Black
  • Color: Black

Testing Standards

  • CSA File Number: LR-29601
  • CSA Standard: C22.2 No. 65-03
  • Prop65 Compliance: WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
  • UL Control Number: 453G
  • UL / CULUS Specification: UL 486A/B Listed
  • UL File Number: E6207

General

  • Bag Quantity: 1
  • Carton Quantity Description: STD PACK QTY 3
  • Dual Rated: Yes
  • NEMA Code: S-588-4
  • UPC Code: 78366907844

Environment and Temperature

  • Environmental Conditions: Cold temperature rated to -45°C
  • Flammability Rating: Insulation rated per UL 94
  • Temperature Rating: 90°C
  • pdfSpec Sheet https://media.distributordatasolutions.com/web_ilsco_v2/2021q4/documents/41bbaeb0c283fa591388f973382a361cf01a7b82.pdf
