G3000CE Wiremold
Wiremold G3000CE WIRG3000CE
Send Print
  1. pin-int

WIRG3000CE

Wiremold G3000CE Steel 5 Foot Gray Raceway Cover

  • Manufacturers: Legrand
  • Brand Name: Wiremold
  • BPN: WIRG3000CE
  • MPN: G3000CE
  • UPC:786776088649
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

The Wiremold 3000 Series Steel Raceway provides wiring capacities for small to medium size installations. Power or data/communication devices can be wired into the raceway for a flush appearance satisfying both aesthetic and functional requirements. The 3000 Series Steel Raceway is ideally suited for wiring applications in frequently changing environments such as labs, hospitals and other industrial applications.

Application      :      Commercial, Office
Brand Name      :      Wiremold
Buy American Compliant      :      Y
Certifications      :      CULUS,NAFTA,ROHS
Color      :      Gray
Component Type      :      Raceway Base & Cover
Country of Origin      :      USA
Depth      :      1/4 Inch
Dimensions      :      5 ft L x 70 mm W
Finish      :      Coated
For Use With      :      3000 Series Raceway
Height      :      2-3/4 Inch
Item Name      :      Cover
Jacket Color      :      Ivory, Gray
Length      :      5 Foot
Material      :      Steel
Product Series      :      3000
Standards      :      cULus Listed, UL File Number E4376, E41751, Meets Article 386 of NEC, Meets Section 12-600 of CEC
Sub Brand      :      Wiremold
Trade Slang      :      786776088649, 3000, Cover, Raceway, WMDG3000CE, Wiremold, G3000CE, 2-Piece Small Raceway - Cover, 2-Piece Small Raceway & Accessories, Raceway - Metallic, Conduit, Ducts, Raceways, power strip
Type      :      Raceway
Voltage Rating      :      600 Volt
Voltage      :      600 Volt
Volume      :      41.25 cu in

Features

Certifications

  • RoHS Compliant
  • NAFTA Compliant
  • cULus Listed
  • Cover - 0.040"" steel. Packed 100 ft. per carton, (20) 5 ft. (1.50m) lengths."

Specifications

  • Depth: 0.25 in
  • Height: 2.75 in
  • Special Features: Low-profile, unobtrusive appearance, Surface mounting, UL5 and ADA compliant, UL and cUL Listed component raceways
  • Weight: 38.81 lb
  • Width: 60.0 in
  • Country of Origin: United States
  • Type: Raceway
  • Voltage: 600.0 V
  • Application Sector: Commercial
  • Standard: cULus Listed Surface Metal Raceway: File E4376: Guide RJBT/RJBT7

Specifications

  • Color: Gray
  • Product Line: Wiremold
  • Product Volume: 41.25
  • linkSpec Sheet https://legrand.webdamdb.com/directdownload.php?ti=55653953&tok=BTvBQtNtzVO9nnpyS0iNBARR
  • linkInstallation / Instruction Manual https://legrand.webdamdb.com/directdownload.php?ti=55653214&tok=wwszCq94vwO7sEEQ/N4YJARR
