ASN-4/0
Ilsco
https://www.billows.com/3363742/product/ILSASN4/0
https://www.billows.com/3363742/product/ILSASN4/0
ILSASN4/0
Ilsco ASN-4/0 SureCrimp® Aluminum Compression Sleeve, Conductor Size 4/0, Tin Plated, UL, CSA
- Manufacturers: ILSCO
- Brand Name: Ilsco
- BPN: ILSASN4/0
- MPN: ASN-4/0
- UPC:783669184792
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at this location:
--
-
Login for Price
- Submit Slang Term
Surecrimp Aluminum Compression Sleeve, Compression connection, Dual Rated, Aluminum material, Tin plated connector, Standard Barrel, UL, CSA, Copper/Aluminum Primary Conductor 4/0 Str, Contains De-Ox®, 1 conductors, Dimensions 3.07 in x 0.854 in x 0.854 in, rated for 35 kV, die color code White, primary color(s) Silver,
| Application | : | Use in Circuits Rated 35 kV or Less, Proper High Voltage Spacing and Insulation Techniques must be used |
| Barrel Type | : | Standard |
| Brand Name | : | Ilsco |
| Carton Qty | : | 10 |
| Color | : | Ruby |
| Conductor Material | : | Aluminum,Copper |
| Conductor Range | : | AL Solid (Primary, run, main, line):NA;CU Solid (Primary, run, main, line):NA;CU Stranded (Primary, run, main, line):4/0 Str;AL Stranded (Primary, run, main, line):4/0 Str |
| Conductor Size | : | 4/0 AWG |
| Conductor Type | : | Aluminum and Copper |
| Connection Type | : | Compression |
| Connection | : | Compression |
| Die Code | : | 467 |
| Dimensions | : | 0.553 in ID x 0.854 in OD |
| Finish | : | Electro-Tin Plated |
| Height | : | 0.854 Inch |
| Inside Diameter | : | 0.553 in |
| Item Name | : | Compression Sleeve |
| Length | : | 3.07 Inch |
| Material | : | Aluminum |
| Number of Conductors | : | 1 |
| Outside Diameter | : | 0.854 in |
| Series | : | ASN |
| Size | : | L:3.07;W:0.854;H:0.854 IN |
| Standards | : | UL 486A/B, UL File Number E6207, CSA File Number LR29601, RoHS Compliant |
| Sub Brand | : | SureCrimp® |
| Temperature Rating | : | 90 °C |
| Trade Slang | : | compression, sleeve, ILSAS400, Ilsco, AS-400, Compression Sleeves - Aluminum - Standard Barrel, Compression Sleeves, Lugs & Split Bolts, Connectors, Crimps, Termination |
| Type | : | Dual Rated, Chamfered Barrel |
| Voltage Rating | : | 35,000 Volt |
| Voltage | : | 35 Volt |
Specifications
- Height: 0.854 in | 21.6916 mm
- Length: 3.07 in | 77.978 mm
- Weight: 0.098 lbs
- Width: 0.854 in | 21.6916 mm
Dimensions
- Height BX (IN): 2.25
- Height (mm): 21.6916
- Inside Diameter (IN): 0.553
- Inside Diameter (mm): 14.0462
- Length (mm): 77.978
- Outside Diameter (IN): 0.854
- Outside Diameter (mm): 21.6916
- Weight BX (LB): 1.083
- Width BX (IN): 5
- Width (mm): 21.6916
Additional Technical Specifications
- Conductor Type: Stranded
Additional Class Attributes
- Barrel Marking: Hard
- Barrel Type: Standard
- Connection: Compression
- Contains DE-OX®: Yes
- Flared End: No
- ILSCOs Die Index Number: 467
- Number of Conductors: 1
Material and Finish
- Conductor Material: Aluminum, Copper
- Connector Finish: Tin
- Material: Aluminum
Conductor Ranges
- Conductor Range AL Stranded (Primary, run, main, line): 4/0 Str
- Conductor Range CU Stranded (Primary, run, main, line): 4/0 Str
- Expanded Conductor Range: 4/0 Str - 1 Str
Environment and Temperature
- Temperature Rating: 90°C
Color
- Color: Silver
- Color Code: White
Voltage
- Voltage Rating: 35 kV
Testing Standards
- CSA File Number: LR-29601
- CSA Standard: C22.2 No. 65-03
- Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
- UL Control Number: 453G
- UL / CULUS Specification: UL 486A/B Listed
- UL File Number: E6207
General
- Bag Quantity: 1
- Carton Quantity Description: STD PACK QTY 10
- Dual Rated: Yes
- NEMA Code: S-588-1
- UPC Code: 78366918479
