GUS2-25YW/D10
RAB
https://www.billows.com/3369183/product/RABGUS225YWD10
https://www.billows.com/3369183/product/RABGUS225YWD10
RABGUS225YWD10
RAB GUS2-25YW/D10 Wraparound Fixture,) LED Lamp, 26 W Fixture, 120 to 277 VAC, White/Polyester Powder Coated Housing
- Manufacturers: RAB Lighting
- Brand Name: RAB
- BPN: RABGUS225YWD10
- MPN: GUS2-25YW/D10
- UPC:019813424187
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at this location:
--
-
Login for Price
- Submit Slang Term
RAB Wraparound Fixture, Series: GUS, 120 to 277 VAC, 26 W Fixture, 0.21/0.14/0.12/0.11 A, LED Lamp, 25 W Lamp, 103 Lumens/W Light Output, 100000 hr Average Life, Warm White Light, 3000 K Color Temperature, 84 CRI, 0 to 10 VDC Dimming/Class 2 Constant Current Ballast, Acrylic Lens, 2666 Lumens, Surface Mounting, Cold Rolled Steel Housing Material, White/Polyester Powder Coated Housing Finish, 2 ft L x 9-3/4 in W x 2-15/16 in H Dimensions
| Amperage Rating | : | 0.21/0.14/0.12/0.11 A |
| Average Life | : | 100000 hr |
| Ballast Type | : | 0 to 10 VDC Dimming/Class 2 Constant Current |
| Color Rendering Index (CRI) | : | 84 |
| Color Temperature | : | 3000 K |
| Dimensions | : | 2 ft L x 9-3/4 in W x 2-15/16 in H |
| Fixture Wattage | : | 26 W |
| Housing Finish | : | White/Polyester Powder Coated |
| Housing Material | : | Cold Rolled Steel |
| Lamp Type | : | LED |
| Lamp Wattage | : | 25 W |
| Lens Type | : | Acrylic |
| Light Color | : | Warm White |
| Light Output | : | 103 Lumens/W |
| Lumens | : | 2666 Lumens |
| Mounting Type | : | Surface |
| Series | : | GUS |
| Voltage Rating | : | 120 to 277 VAC |
- Energy efficient, maintenance free LED wrap fixture
- High reflectance white finish for optimal output
- Diffusion wrap around lens for smooth light distribution
- Surface, pendant or chain multiple mounting options
- Formulated for high durability and long lasting color
- Long life and high efficiency LEDs
- 0.21 A at 120 VAC, 0.14 A at 208 VAC, 0.12 A at 240 VAC, 0.11 A at 277 VAC
Instruction/Installation Manual
Line Drawing
