CHDCHMMB100BTS

EATON CHMMB100BTS Type CH 4-Circuit 3-Wire All-In-One Horn bypass Combination Service Entrance Non-EUSERC Meter Main Breaker, 120/240 VAC, 100 A, 1 ph Phase, NEMA 3R Enclosure

  • Manufacturers: Eaton
  • Brand Name: EATON
  • BPN: CHDCHMMB100BTS
  • MPN: CHMMB100BTS
  • UPC:782113682006
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

EATON's residential meter breakers are service entrance equipment systems that consist of a single meter socket and load center (circuit breaker distribution section) or meter socket and main breaker combined in one enclosure.

EATON Meter Main Breaker, Type CH 4-Circuit 3-Wire All-In-One Horn bypass Combination Service Entrance Non-EUSERC, Series: CHMM, 120/240 VAC, 100 A, 1 ph Phase, Bottom/Overhead/Top/Underground Feed, 5 Jaws, Top Endwall, 3/4 in Hub, Ringless Cover, Surface Mount, NEMA 3R, 4.93 in L x 13 in W x 23.87 in H

Amperage Rating      :      100 A
Cover Type      :      Ringless
Dimensions      :      4.93 in L x 13 in W x 23.87 in H
Enclosure Type      :      NEMA 3R
Feed Type      :      Bottom/Overhead/Top/Underground
Hub Size      :      3/4 in
Hub Type      :      Top Endwall
Mounting Type      :      Surface
Number of Jaws      :      5
Phase      :      1 ph
Series      :      CHMM
Type      :      Type CH 4-Circuit 3-Wire All-In-One Horn bypass Combination Service Entrance Non-EUSERC
Voltage Rating      :      120/240 VAC
  • Larger lay-in lugs and 3 in knockouts for ease of installation
  • Factory installed neutral assemblies
  • Hub provisions on top endwall
  • Padlockable device covers provide an additional measure of security and help prevent tampering
  • Without distribution section
  • pdfCatalog https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_97979633dcaf4fc709f75ff7065ec843bc98a0d71d8e84549a700c5f2f44069d.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_c71df64947c3f206e8e682c1b18243631801bce38de45545398ca24283d38565.pdf
