EATON Arrow Hart® 1995RD 1995 3-Position Center OFF Momentary Contact Industrial Grade Toggle Switch, 120/277 VAC, 20 A

  • Manufacturers: Eaton
  • Brand Name: EATON
  • BPN: CWD1995RD
  • MPN: 1995RD
  • UPC:040893686028
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

EATON Arrow Hart® Toggle Switch, 3-Position Center OFF Momentary Contact Industrial Grade, Series: 1995, 120/277 VAC, 20 A, 1 Pole, Toggle Actuator, Screw Terminal, Red, 1.31 in L x 1 in W x 3.28 in H Dimensions

Actuator      :      Toggle
Amperage Rating      :      20 A
Color      :      Red
Dimensions      :      1.31 in L x 1 in W x 3.28 in H
Number of Poles      :      1
Series      :      1995
Terminal Type      :      Screw
Type      :      3-Position Center OFF Momentary Contact Industrial Grade
Voltage Rating      :      120/277 VAC
  • Incorporating the most durable design elements in the industry Arrow Hart® broad line of industrial grade switches feature superior engineering, reliable performance and ease of installation
  • Automatic grounding eliminates need for bonding jumper in metal enclosures
  • Color coded faces identify amperage - blue 15 A, red 20 A, green 30 A
  • Robust nylon toggle for heavy usage areas
  • Heavy gauge 0.05 in plated steel mounting strap withstands corrosion
  • Tri-combo head terminal and mounting screws, plus easy access grounding terminal
  • Dual back wire holes for maximum feed-through wiring flexibility, accepts up to 10 AWG solid or stranded wire
  • 1-piece brass contact arm and large silver alloy contact assures low resistance switching
  • Patent pending spring cup toggle design for consistent positive activation
