65W49BK EATON
EATON 65W49BK CWD65W49BK
Send Print
  1. pin-int

CWD65W49BK

EATON Arrow Hart® Hart-Lock® 65W49BK Single Watertight Locking Receptacle, 250 VAC, 15 A, 2 Poles, 3 Wires, Black

  • Manufacturers: Eaton
  • Brand Name: EATON
  • BPN: CWD65W49BK
  • MPN: 65W49BK
  • UPC:032664708640
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

EATON Arrow Hart® Hart-Lock® Locking Receptacle, Single Watertight, 250 VAC, 15 A, 2 Pole, 3 Wires, L6-15 NEMA Rating, Industrial Grade, 0.3 to 0.65 in Diameter Cord, Back Wire Terminal, Thermoplastic/Glass-Filled Nylon, Black

Amperage Rating      :      15 A
Color      :      Black
Cord Diameter      :      0.3 to 0.65 in
Grade      :      Industrial
Material      :      Thermoplastic/Glass-Filled Nylon
NEMA Rating      :      L6-15
Number of Poles      :      2
Number of Wires      :      3
Terminal Type      :      Back Wire
Type      :      Single Watertight
Voltage Rating      :      250 VAC
  • EATON's Arrow Hart® watertight locking devices utilize a unique, robust design and superior materials to provide watertight security in harsh environments
  • Santoprene™ elastomeric exteriors with innovative triple sealing system provides watertight performance that is resistant to chemicals and severe washdown environment
  • Nickel plated blades, contacts and terminal screws provide corrosion resistance
  • Receptacles have glass-filled nylon exterior shells and spring-loaded covers that provide impact resistance in harsh environments and a NEMA 4X watertight rating when covers are closed or when mated with a watertight plug
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_4d60b71acf40b5f36cf49cb7dcb8c0d20ce5020a6bc380fbe11d5df193f25bf7.pdf
