5662CV
EATON
https://www.billows.com/3409398/product/CWD5662CV
https://www.billows.com/3409398/product/CWD5662CV
CWD5662CV
EATON Arrow Hart™ Eaton Wiring Devices 5662CV Duplex Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Ivory
- Manufacturers: Eaton
- Brand Name: EATON
- BPN: CWD5662CV
- MPN: 5662CV
- UPC:040893620831
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at this location:
--
-
Login for Price
- Submit Slang Term
Construction specification grade straight blade receptacles - 20 A, 125 VAC, NEMA 5-20R. Engineered for safe, reliable performance, these UL 498 and Federal Specification W-C-596 listed devices provide maximum durability in a wide variety of applications while providing installation efficiency to help finish the job on time.
EATON Arrow Hart™ Eaton Wiring Devices Straight Blade Receptacle, Duplex, 125 VAC, 15 A, 2 Pole, 3 Wires, NEMA 6-15R NEMA Rating, Construction/Industrial Grade, -20 to 70 deg C, Screw Terminal, Nylon, Ivory, 4.19 in H x 1.3 in W x 0.87 in D Dimensions
| Amperage Rating | : | 15 A |
| Color | : | Ivory |
| Dimensions | : | 4.19 in H x 1.3 in W x 0.87 in D |
| Grade | : | Construction/Industrial |
| Material | : | Nylon |
| NEMA Rating | : | NEMA 6-15R |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Temperature Rating | : | -20 to 70 deg C |
| Terminal Type | : | Screw |
| Type | : | Duplex |
| Voltage Rating | : | 125 VAC |
- Convenient built-in 10 and 12 AWG wire strippers
- All terminal and mounting screws Triple-combination (slot/Phillips®/Robertson) head for maximum installer flexibility
- Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure, provides redundant measure of ground continuity where jumper is used
- Extra long/wide mounting strap maintains assembly security and helps reach oversize cut-outs
