CWD8200W
EATON Arrow Hart™ Eaton Wiring Devices 8200W Single Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, White
- Manufacturers: Eaton
- Brand Name: EATON
- BPN: CWD8200W
- MPN: 8200W
- UPC:032664705458
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at this location:
--
-
Login for Price
- Submit Slang Term
Hospital specification grade straight blade receptacles - back wire and side wire. Arrow Hart™ feature rich line of hospital grade receptacles have been designed to meet and exceed the demanding requirements of UL 498 and Federal Specification W-C-596 to provide a consistent means of connectivity where downtime can be critical.
EATON Arrow Hart™ Eaton Wiring Devices Straight Blade Receptacle, Single, 125 VAC, 15 A, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Industrial/Hospital Grade, -20 to 90 deg C, Screw Terminal, Nylon, White, 4.19 in H x 1.3 in W x 0.88 in D Dimensions
| Amperage Rating | : | 15 A |
| Color | : | White |
| Dimensions | : | 4.19 in H x 1.3 in W x 0.88 in D |
| Grade | : | Industrial/Hospital |
| Material | : | Nylon |
| NEMA Rating | : | NEMA 5-15R |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Temperature Rating | : | -20 to 90 deg C |
| Terminal Type | : | Screw |
| Type | : | Single |
| Voltage Rating | : | 125 VAC |
- Tapered back wiring lead-in slots assist in gathering stranded wires for faster, more secure connections
- Long, broad mounting strap helps reach large panel cut-outs for code compliance
- Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure, provides redundant measure of ground continuity where jumper is used
- All terminal and mounting screws Triple-combination (slot/Phillips®/Robertson) head for maximum installer flexibility
- Screw catch feature on duplex devices speeds mounting of wallplates
- Nylon insulation
- Wall mount
- 14 to 10 AWG wire terminal
