L730RW EATON
EATON L730RW CWDL730RW
Send Print
  1. pin-int

CWDL730RW

EATON Arrow Hart® Hart-Lock® L730RW Single Locking Receptacle, 277 V, 30 A, 2 Poles, 3 Wires, Yellow

  • Manufacturers: Eaton
  • Brand Name: EATON
  • BPN: CWDL730RW
  • MPN: L730RW
  • UPC:040893687674
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

EATON Arrow Hart® Hart-Lock® Locking Receptacle, Single, 277 V, 30 A, 2 Pole, 3 Wires, L7 to 30 NEMA Rating, Industrial Grade, Back Wire Terminal, Thermoplastic, Yellow, 6-3/4 in L x 4-1/4 in W x 4 in H Dimensions

Amperage Rating      :      30 A
Color      :      Yellow
Dimensions      :      6-3/4 in L x 4-1/4 in W x 4 in H
Grade      :      Industrial
Material      :      Thermoplastic
NEMA Rating      :      L7 to 30
Number of Poles      :      2
Number of Wires      :      3
Terminal Type      :      Back Wire
Type      :      Single
Voltage Rating      :      277 V
  • 14 to 8 AWG wire
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_d2bb29e2b96ef958170f1f7f2c55e3925b9ca33c7737fb2b525207723d8508fc.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_ded07a1bae327910db03b738c46161d9dcec1b3459e346193e186508429e3f7b.pdf
