9544SG EATON
EATON 9544SG CWD9544SG
Send Print
  1. pin-int

CWD9544SG

EATON ASPIRE™ 9544SG 1-Pole 3-Speed Quiet Fan Control Switch, 120 VAC, 1.5 A, Preset Operational Mode, Polycarbonate, Silver Granite

  • Manufacturers: Eaton
  • Brand Name: EATON
  • BPN: CWD9544SG
  • MPN: 9544SG
  • UPC:032664658341
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

Eaton's fan controls vary the speed of air flow and employ special circuitry to quiet the fan's motor at low speeds. Install the device in place of a standard switch to add convenient fan control with quiet, smooth actuation. Tri-combo and ground screws help allow easy accesibility and installation. The top and back body are virtually unbreakable, and the device features electrostatic discharge protection, radio frequency interface filtering, and power failure memory. Eaton fan controls are available with color change kits and are compatible with traditional-style or screwless wallplates.

EATON ASPIRE™ Fan Control Switch, 1-Pole 3-Speed Quiet, 120 VAC, 1.5 A, 3-Way/Preset/Maintained Operational Mode, Flush Mounting, Lead Wire Terminal, 32 to 104 deg C, Polycarbonate, Silver Granite, 3 in L x 2.13 in W x 4.5 in H Dimensions

Amperage Rating      :      1.5 A
Color      :      Silver Granite
Dimensions      :      3 in L x 2.13 in W x 4.5 in H
Material      :      Polycarbonate
Mounting      :      Flush
Operational Mode      :      Preset
Temperature Rating      :      32 to 104 deg C
Terminal Type      :      Lead Wire
Type      :      1-Pole 3-Speed Quiet
Voltage Rating      :      120 VAC
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_0a500c066ebacf2bd890d8ff80955188a7160ecbd7d4cd695dfd1606e59fcf31.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_97d0ac17a189d726ed120810cbd9ecd659fb51f78e370b1dfaf55d30bbaade64.pdf
