EATON Arrow Hart™ Eaton Wiring Devices 826V-BOX Non-Grounding Premium Single Tamper-Resistant Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Ivory

  • Manufacturers: Eaton
  • Brand Name: EATON
  • MPN: 826V-BOX
  • UPC:032664182709
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

Commercial specification grade straight blade receptacles - 15 A, 250 VAC, NEMA 6-15R. engineered for safe, reliable performance, these UL 498 and Federal Specification W-C-596 listed devices provide maximum durability in a wide variety of applications while providing installation efficiency to help finish the job on time.

EATON Arrow Hart™ Eaton Wiring Devices Straight Blade Receptacle, Non-Grounding Premium Single Tamper-Resistant, 125 VAC, 15 A, 2 Pole, 3 Wires, NEMA 6-15R NEMA Rating, Commercial/Hospital Grade, -4 to 158 deg F, Screw Terminal, Glass Filled Nylon, Ivory, 4.19 in H x 1.3 in W x 0.82 in D Dimensions

Amperage Rating      :      15 A
Color      :      Ivory
Dimensions      :      4.19 in H x 1.3 in W x 0.82 in D
Grade      :      Commercial/Hospital
Material      :      Glass Filled Nylon
NEMA Rating      :      NEMA 6-15R
Number of Poles      :      2
Number of Wires      :      3
Temperature Rating      :      -4 to 158 deg F
Terminal Type      :      Screw
Type      :      Non-Grounding Premium Single Tamper-Resistant
Voltage Rating      :      125 VAC
  • Galvanized steel, wraparound yoke mounting strap for superior assembly security, extra length/width helps reach large panel cut-outs for code compliance
  • Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure, provides redundant measure of ground continuity where jumper is used
  • Screw catch feature on duplex devices speeds mounting of wallplates
  • Tamper-resistant receptacles provide compliance with 2014 NEC Article 406.12 that states that all 15 A and 20 A, 125 VAC receptacles installed in dwelling units must be tamper-resistant
  • Nylon face, glass filled nylon base
  • Nylon insulation
  • Flush mounting
  • 14 to 10 AWG wire terminal
