L1030RW EATON
EATON L1030RW CWDL1030RW
Send Print
  1. pin-int

CWDL1030RW

EATON Arrow Hart® Hart-Lock® L1030RW Single Locking Receptacle, 125/250 V, 30 A, 3 Poles, 3 Wires, Yellow

  • Manufacturers: Eaton
  • Brand Name: EATON
  • BPN: CWDL1030RW
  • MPN: L1030RW
  • UPC:040893687728
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

EATON Arrow Hart® Hart-Lock® Locking Receptacle, Single, 125/250 V, 30 A, 3 Pole, 3 Wires, L10 to 30 NEMA Rating, Industrial Grade, Back Wire Terminal, Thermoplastic, Yellow, 6-3/4 in L x 4-1/4 in W x 4 in H Dimensions

Amperage Rating      :      30 A
Color      :      Yellow
Dimensions      :      6-3/4 in L x 4-1/4 in W x 4 in H
Grade      :      Industrial
Material      :      Thermoplastic
NEMA Rating      :      L10 to 30
Number of Poles      :      3
Number of Wires      :      3
Terminal Type      :      Back Wire
Type      :      Single
Voltage Rating      :      125/250 V
  • 14 to 8 AWG wire
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Crouse-Hinds_L1030RW_Brochure.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_8983cb89a98ce18ea3b61a044428d2d2ca71d0af9309bc2efea0d24f7a913db4.pdf
