PJ5BK EATON
EATON PJ5BK CWDPJ5BK
Send Print
  1. pin-int

CWDPJ5BK

EATON Arrow Hart™ Eaton Wiring Devices PJ5BK Mid-Sized Toggle Switch Wallplate, 5 Gangs, 4.87 in H x 10.37 in W, Polycarbonate, Black

  • Manufacturers: Eaton
  • Brand Name: EATON
  • BPN: CWDPJ5BK
  • MPN: PJ5BK
  • UPC:032664628061
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

Mid size wallplates - polycarbonate toggle polycarbonate wallplates are virtually unbreakable, with high structural rigidity, long term form retention and superior impact and abrasion resistance. Rugged construction reduces installation cost due to less plate breakage and resists bowing to provide a smooth, flat installation. Exclusive time saving screw catch feature (see adjoining illustration) that holds mounting screws captive and simplifies installation. High gloss finish is soil-resistant. Nylon wallplates have a flush fitting, warp-resistant design. Polycarbonate wallplates are virtually unbreakable, with high structural rigidity, long term form retention and superior impact and abrasion resistance. Matching mounting screws provided.

EATON Arrow Hart™ Eaton Wiring Devices Toggle Switch Wallplate, Mid-Sized, Series: PJ Series, 5 Gangs, 5 Ports, 4.87 in H x 10.37 in W Size, (5) 0.93 in H x 0.4 in W Toggle Switch Cutout, Threaded Mounting, Superior Impact-Resistance Construction, 0.08 in Thickness, Polycarbonate, Black, High Gloss

Color      :      Black
Construction      :      Superior Impact-Resistance
Cutout      :      (5) 0.93 in H x 0.4 in W Toggle Switch
Finish      :      High Gloss
Material      :      Polycarbonate
Mounting      :      Threaded
Number of Gangs      :      5
Number of Ports      :      5
Series      :      PJ Series
Size      :      4.87 in H x 10.37 in W
Thickness      :      0.08 in
Type      :      Mid-Sized
  • Virtually unbreakable plates reduce installation and replacement costs
  • Exclusive time-saving screw catch feature holds mounting screws captive and simplifies installation
  • -40 to 158 deg f temperature rating
  • Injection molded
  • 0.93 in H x 0.4 in W opening configuration
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_f466b0ad76836a2915a96ccbecd2189b68c9e1b16a96c36f2fe173f6c0c6bd18.pdf
