7411PWBK EATON
EATON 7411PWBK CWD7411PWBK
Send Print
  1. pin-int

CWD7411PWBK

EATON Arrow Hart® 7411PWBK Watertight Locking Plug, 120/208 VAC, 20 A, 4 Poles, 4 Wires, Black

  • Manufacturers: Eaton
  • Brand Name: EATON
  • BPN: CWD7411PWBK
  • MPN: 7411PWBK
  • UPC:032664708688
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

EATON's Arrow Hart® watertight locking devices utilize a unique, robust design and superior materials to provide watertight security in harsh environments.

EATON Arrow Hart® Locking Plug, Watertight, 120/208 VAC, 20 A, 4 Pole, 4 Wires, IP67 Enclosure, 0.43 to 1.15 in Diameter Cord, -40 to 167 deg F, Back Wire Terminal, Glass Reinforced Polypropylene, Black, 2.69 in W Dimensions

Amperage Rating      :      20 A
Color      :      Black
Cord Diameter      :      0.43 to 1.15 in
Dimensions      :      2.69 in W
Enclosure      :      IP67
Material      :      Glass Reinforced Polypropylene
Number of Poles      :      4
Number of Wires      :      4
Temperature Rating      :      -40 to 167 deg F
Terminal Type      :      Back Wire
Type      :      Watertight
Voltage Rating      :      120/208 VAC
  • Santoprene™ elastomeric exteriors with innovative triple sealing system provides watertight performance that is resistant to chemicals and severe washdown environment
  • Nickel plated blades, contacts and terminal screws provide corrosion resistance
  • Plugs and connectors have glass reinforced polypropylene interiors that provide strength and durability and when mated they have a NEMA 4X and IP67 watertight rating
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_14W33BK_Catalog.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_4d60b71acf40b5f36cf49cb7dcb8c0d20ce5020a6bc380fbe11d5df193f25bf7.pdf
