EATON ASPIRE™ 9573DS 3-Way Slide Dimmer, 120 VAC, 1 Poles, Desert Sand

  • Manufacturers: Eaton
  • Brand Name: EATON
  • BPN: CWD9573DS
  • MPN: 9573DS
  • UPC:032664726552
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

Cooper® wiring devices ASPIRE™ LED and CFL dimmers provide full range classic linear slide dimming for 300 W dimmable CFL and LED as well as 600 W incandescent and halogen light sources. These units are ideal for residential and light commercial applications and are compatible with Cooper® wiring devices decorator style devices and wallplates preset units feature a preset ON-OFF in switch that automatically returns controlled lights to a preset level without disturbing the brightness level. The device is designed for both 1-pole (one location) and 3-way (multi-location) applications.

EATON ASPIRE™ Slide Dimmer, 3-Way, 120 VAC, 300/600 W Power, 60 Hz Frequency, 1 Pole, CFL/Incandescent/LED Lamp, Preset Start, Push Pad Control, Flush Mounting, Back/Side Wire/Wire Lead Terminal, 0 to 40 deg C, Polycarbonate, Desert Sand, 1.8 in W x 1.27 in D x 3.81 in H Dimensions

Color      :      Desert Sand
Control      :      Push Pad
Dimensions      :      1.8 in W x 1.27 in D x 3.81 in H
Frequency Rating      :      60 Hz
Lamp Type      :      CFL/Incandescent/LED
Material      :      Polycarbonate
Mounting Type      :      Flush
Number of Poles      :      1
Power Rating      :      300/600 W
Start Type      :      Preset
Temperature Rating      :      0 to 40 deg C
Terminal Type      :      Back/Side Wire/Wire Lead
Type      :      3-Way
Voltage Rating      :      120 VAC
  • Preset feature allows user to return to previous light level when turning lights on
  • Integrated full slide control for easy, precise operation
  • Preset versions can be wired as 1-pole or 3-way
  • Device can be wired into either 3-way location (load side or line side)
  • Neutral is not required for installation of device
  • Replaces a standard switch and offers dimmer capabilities
  • Power failure memory
  • Radio frequency interface (RFI) filtering is standard on all models
  • Electrostatic discharge protection
  • Precise color matching
  • Compatible with any decorator wallplate or screwless wallplate
  • Compatible with many dimmable CFL and LED lamps
  • Decorator form factor
