L1130CWBK
EATON
https://www.billows.com/3410681/product/CWDL1130CWBK
https://www.billows.com/3410681/product/CWDL1130CWBK
CWDL1130CWBK
EATON Arrow Hart® L1130CWBK 3-Phase Complex Environment Non-Grounding Watertight Locking Connector, 250 VAC, 30 A, 3 Poles, 3 Wires, Black
- Manufacturers: Eaton
- Brand Name: EATON
- BPN: CWDL1130CWBK
- MPN: L1130CWBK
- UPC:032664708886
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at this location:
--
-
Login for Price
- Submit Slang Term
EATON Arrow Hart® Locking Connector, 3-Phase Complex Environment Non-Grounding Watertight, 250 VAC, 30 A, 3 Pole, 3 Wires, NEMA L11-30 NEMA Rating, Industrial/Specification Grade, NEMA 4/4X/6/6P/IP67 Enclosure, 0.43 to 1.15 in Diameter Cord, -40 to 167 deg F, Screw Terminal, Nylon/Santoprene Thermoplastic Elastomeric, Black, 6.38 in L x 4.4 in W x 3.82 in H
| Amperage Rating | : | 30 A |
| Color | : | Black |
| Cord Diameter | : | 0.43 to 1.15 in |
| Dimensions | : | 6.38 in L x 4.4 in W x 3.82 in H |
| Enclosure | : | NEMA 4/4X/6/6P/IP67 |
| Grade | : | Industrial/Specification |
| Material | : | Nylon/Santoprene Thermoplastic Elastomeric |
| NEMA Rating | : | NEMA L11-30 |
| Number of Poles | : | 3 |
| Number of Wires | : | 3 |
| Temperature Rating | : | -40 to 167 deg F |
| Terminal Type | : | Screw |
| Type | : | 3-Phase Complex Environment Non-Grounding Watertight |
| Voltage Rating | : | 250 VAC |
- Thermoplastic elastomeric exterior out performs rubber when exposed to moisture, chemicals, oils and the effects of UV exposure and ozone attack
- Meets NEMA and IEC IP ratings and withstands water spray test at 1000 psi
- High visibility safety yellow for identification
- Power contacts, blades and terminal screws nickel plated for corrosion resistance
- Quick drive stainless steel assembly screws for corrosion resistance and fast installation
- Color coded neoprene grommets for a watertight seal on a wide range of cord sizes
