HCP368H Siemens
Siemens HCP368H ITEHCP368H
Send Print
  1. pin-int

ITEHCP368H

Siemens HCP368H F2/FPP6/SWBD, HC

  • Manufacturers: Siemens
  • Brand Name: Siemens
  • BPN: ITEHCP368H
  • MPN: HCP368H
  • UPC:783643308817
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

SIEMENS LOW VOLTAGE HCP SWITCH DISCONNECT FOR SWITCHBOARD UNITS. 3-POLE HORIZONTAL MOUNT SWITCH WITH L CLASS FUSE PROVISION. RATED 600V (1200A). DIMENSIONS (H x W x D) IN 16.25 x 17.22 x 7.38.

Amperage Rating      :      1,200 Amp
Amperage      :      1200 Amp
Application      :      Switches
Brand Name      :      Siemens
ETIM 7 Class      :      EC002498
Frequency Rating      :      60 Hz
Mounting      :      Horizontal Mount
Number of Poles      :      3 Pole
Operating Cycles      :      2500
Operating Temperature      :      -20F to 120F Ambient Temp
Size      :      10x18x20
Standards      :      UL
Sub Brand      :      Panelboard/Switchboard Units
  • pdfSpec Sheet https://digitalcontentcenter.compas.siemens-info.com/type_hcp-switch.pdf
