HQR22B150 Siemens
Siemens HQR22B150 ITEHQR22B150
Send Print
  1. pin-int

ITEHQR22B150

Siemens HQR22B150 QR MCCB,65kA@2

  • Manufacturers: Siemens
  • Brand Name: Siemens
  • BPN: ITEHQR22B150
  • MPN: HQR22B150
  • UPC:804766136344
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

Type QR Molded Case Circuit Breaker, 65kA @ 240V, 2 Poles, 150A, Standard 40 Degree Celsius Breaker, Thermal Magnetic

Amperage Rating      :      150 Amp
Amperage      :      150 Amp
Application      :      Circuit Protection
Brand Name      :      Siemens
Connection      :      Load Lugs
ETIM 7 Class      :      EC002498
Frame      :      QR
Frequency Rating      :      50/60 Hz
Height      :      7 Inch
Interrupt Rating      :      65 kAIC
Item Name      :      Molded Case Circuit Breaker
Number of Poles      :      2 Pole
Operating Temperature      :      40DEGC
Standards      :      UL489/CSA-C22.2/NOM-003
Sub Brand      :      Siemens
Temperature Rating      :      40 °C
Terminal Connection      :      Load Lugs
  • linkSpec Sheet https://mall.industry.siemens.com/tedservices/DatasheetService/DatasheetService?format=PDF&caller=PDPS&mlfbs=US2:HQR22B150&language=en
