HQR23B200H Siemens
Siemens HQR23B200H ITEHQR23B200H
Send Print
  1. pin-int

ITEHQR23B200H

Siemens HQR23B200H QR MCCB,100kA

  • Manufacturers: Siemens
  • Brand Name: Siemens
  • BPN: ITEHQR23B200H
  • MPN: HQR23B200H
  • UPC:804766137082
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

SIEMENS LOW VOLTAGE MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP. QR FRAME STANDARD 40C BREAKER. 200A 3-POLE (100KA AT 240V). SPECIAL FEATURES NO LUGS INSTALLED.

Amperage Rating      :      200A
Amperage      :      200A
Application      :      CIRCUIT PROTECTION
Brand Name      :      Siemens
Connection      :      LOAD LUGS
Current Rating      :      200 Amp
Current      :      200 Amp
ETIM 7 Class      :      EC002498
Frame      :      QR FRAME
Frequency Rating      :      50/60 Hz
Height      :      7 Inch
Interrupt Rating      :      100 kAIC
Material      :      MOLDED CASE CIRCUIT BREAKER
Number of Poles      :      3 Pole
Operating Temperature      :      40DEGC
Standards      :      UL489/CSA-C22.2/NOM-003
Sub Brand      :      QR
  • linkSpec Sheet https://mall.industry.siemens.com/tedservices/DatasheetService/DatasheetService?format=PDF&caller=EGH&mlfbs=US2:HQR23B200H&language=en
