HNF361G Siemens
Siemens HNF361G ITEHNF361G
Send Print
  1. pin-int

ITEHNF361G

Siemens HNF361G HDSS NF 3P3W 600V 30A N

  • Manufacturers: Siemens
  • Brand Name: Siemens
  • BPN: ITEHNF361G
  • MPN: HNF361G
  • UPC:783643333819
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Available at this location: loading -- Locations

Siemens Low Voltage Circuit Protection Heavy Duty Safety Switch. 3-Pole Non-Fused in a type 1 enclosure (indoor). Rated 600VAC (30A). Special features: factory installed ground bar.

Action      :      SINGLE THROW
Actuator      :      SINGLETHROW
Amperage Rating      :      30 Amp
Amperage      :      30 Amp
Application      :      DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS
Brand Name      :      Siemens
Connection Type      :      MECHANICAL LUGS
Connection      :      MECHANICALLUGS
Country of Origin      :      USA
ETIM 7 Class      :      EC002498
Enclosure Standard      :      NEMA1
Frequency Rating      :      TRUE
Height      :      8 Inch
Insulation      :      None
Length      :      15 Inch
Material      :      Steel
Mounting      :      SURFACE
Number of Poles      :      3 Pole
Operating Cycles      :      10000
Operating Temperature      :      -29 °C
RoHS Indicator      :      Unknown
Standards      :      UL98
Sub Brand      :      VBII

Specifications

  • Country of Origin: US
  • Standard: UL98
  • Material: STEEL
  • Enclosure: TYPE 1
  • Mounting: SURFACE
  • Number of Poles: 3
  • Amperage Rating: 30
  • Brand Name: SIEMENS
  • Actuator: SINGLE THROW
  • Frequency Rating: true
  • Operating Cycles: 10000
  • Type: HEAVY DUTY SWITCH
  • Connection: MECHANICAL LUGS
  • Special Features: FACTORY INSTALLED GROUND BAR
  • Application: DISCONNECTING MEAN FOR SERVICE ENTRANCE / LOADS
  • pdfSpec Sheet https://media.distributordatasolutions.com/siemenscomplete/2021q3/documents/aaf90d7568cbfc22d9f045166839bd3107980349.pdf
